inverter tube

DC / AC converter adopts full-bridge inverter power tube adopts RCD snubber , and output filter adopts spike suppression filters .

DC/AC变换器采用传统全桥逆变电路，功率管采用RCD吸收电路，输出滤波器采用尖峰抑制滤波器。

Secondly , to H bridge inverter and MOS tube synchronous rectifier principle , and analyzed by simulation confirm the application of synchronous rectifier brings MOS tube of power efficiency than fast recovery power diode to much higher .

其次，对H桥逆变及MOS管同步整流原理加以分析，并通过仿真证实了应用MOS管同步整流所带来的电源效率比快恢复整流二极管要高的多。
